Hydrostatic Head Pressure Tester is used to measure the impermeability of various fabrics that have undergone water-repellent treatment.
Brand:
AVENOItem NO.:
AG17Payment:
T/T, L/CProduct Origin:
ChinaShipping Port:
Xiamen portLead Time：
3-7daysApplication
Hydrostatic Head Pressure Tester is used to measure the impermeability of various fabrics that have undergone water-repellent treatment, such as canvas, tarpaulin, tent cloth, tarpaulin, rainproof clothing cloth and geotextile materials.
Feature
1. Built-in water tank, original water pressure rate balance system, rise speed stable and accurate.
2. Microcomputer programmed, LCD menu, built-in two testing methods.
3. The unit of measurement is free to set, pa, Kpa, mmHg, cmH2O.
Standards
GB / T 4744, AATCC 127, ISO 811, BS EN 20811, BS 3321, 3424-26, JIS L 1092A / B, FZ / T 01004
Dimensions & Weight
Model
AG17-1
AG17-2
AG17-3
Dimensions
55×40×50cm
Weight
50kg
Key Specification
|
Model |
AG17-1 |
AG17-2 |
AG17-3 |
|
Measuring range |
50Kpa |
200kPa |
500kPa |
|
Water pressure rise rate |
1-100Kpa/min |
||
|
Test accuracy |
0.2%F. S |
||
|
Test area |
100cm², 7.8cm² （optional or customized） |
||
|
Test method |
Supercharging method, leakage method |
||
|
Unit |
Pa, Kpa, mmHg, cmH2O freely set |
||
|
Power Supply |
AC220V, 50/60HZ |
||
Standard Accessories
Model
AG17-1
AG17-2
AG17-3
100cm² griper
1set
Calibration plate
1set
Rubber ring
1set
Power line
1set
Option Accessories
|
Model |
AG17-1 |
AG17-2 |
AG17-3 |
|
Other size of griper |
|
||
