Air-cooled light color fastness tester is suitable for light color fastness, weather color fastness, light perspiration color fastness, light aging test of textiles, rubber, dyes, plastics, coatings, paints, dentists and other materials.
Brand:
AVENOItem NO.:
AC01Payment:
T/T, L/CProduct Origin:
ChinaShipping Port:
Xiamen portLead Time:
7-10 daysApplication
Air-cooled light color fastness tester is suitable for light color fastness, weather color fastness, light perspiration color fastness, light aging test of textiles, rubber, dyes, plastics, coatings, paints, dentists and other materials. The Air-cool Light Fastness Tester has a rotating sample holder.
Standards
JIS L0843, GB/T 16422.1, GB/T 14576, GB/T 9344, GB/T 8427, GB/T 1189, GB/T 8430, ISO 105-B02/B04, AATCC TM16, M&S C09/C09A, ASTM G26, G155, ASTM D2565 D4459 D6695
Dimension & Weight
Model |
AC01 Air-cool Light Fastness Tester |
Dimensions |
120×90×180cm |
Weight |
350kg |
Key Specification
Model |
AC01 Air-cool Light Fastness Tester |
Temperature range |
25~50℃, ±0.1℃ (can be custom made high temperature) |
Humidity range |
Light cycle: 10~70RH%, ±0.1RH% Dark cycle: 30~95RH%, ±0.1RH% |
Test time range |
≤10000h |
Irradiance control range |
0.8~1.5W/m²@420nm, Option: 340nm, 300-400nm or 280-800nm Digital setting, automatic compensation |
Standard blackboard thermometer |
40~105℃, ±0.1℃ |
Xenon arc lamp rated power |
2.5kW |
Rotation speed of the sample frame |
5rpm |
Distribution diameter of sample clamp |
Φ550mm |
Capacity (Sample holder) |
AC01-1: ISO: 145×45mm12pcs AATCC: 145×70mm 6pcs, option |
AC01-2: ISO: 145×45mm16pcs AATCC: 145×70mm 8pcs, option |
|
AC01-3: ISO: 145×45mm 24pcs AATCC: 145×70mm 18pcs, option |
Standard Accessories
Model |
AC01 Air-cool Light Fastness Tester |
145*45mm sample holder for ISO and GB standard (AC01-1: 12pcs, AC01-2: 16pcs, AC01-3: Double layer 12pcs) |
1set |
45mm Cover plate, 1/2, 1/3, 3/2 3size (AC01-1: 12pcs, AC01-2: 16pcs, AC01-3: 12pcs) |
1sets |
145*70mm sample holder for AATCC standard (AC01-1: 6pcs, AC01-2: 8pcs, AC01-3: Double layer 9pcs) |
1set |
70mm Cover plate (1/2,1/3 2size) (AC01-1: 12pcs, AC01-2: 16pcs, AC01-3: Double layer 18pcs) |
1set |
Sample board (AC01-1: 60pcs, AC01-2: 60pcs, AC01-3: Double layer 90pcs) |
61set |
Lock ring for lamp (installed in main machine) |
1set |
Xenon lamp air-cooled lamp holder (installed in main machine) |
1set |
Xenon arc lamp (1pc in main machine, 1pc spare) |
2pcs |
Standard blackboard thermometer |
1pc |
Filter glass tube (1pc in main machine, 1pc spare) |
2pcs |
Filter (7pcs in main machine, 7pcs spare) |
14pcs |
Solar panel (spare) |
1pc |
Blue wool standard sample |
1set |
Grey scale |
1set |
Ceramic plate |
2pc |
PP cotton |
2pc |
Inner hexagon spanner |
1pc |
Fuse (5A) |
2pcs |
Drainage intake pipe |
1set |
